The Moxa PTC-101-M-ST-HV is an industrial 10/100BaseT(X) to 100BaseFX media converter, multi-mode with ST connector, 1 isolated power supply (88 to 300 VDC or 85 to 264 VAC), -40 to 85°C operating temperature.
Key specifications
| Product Type | Ethernet-to-Fiber Media Converters |
|---|---|
| 10/100BaseT(X) Ports (RJ45 connector) | 1 |
| 100BaseFX Ports (multi-mode ST connector) | 1 |
| Fiber Wavelength | 1300 nm |
| Typical Fiber Distance | 5 km (50/125 µm), 4 km (62.5/125 µm) |
| Operating Temperature | -40 to 85°C (-40 to 185°F) |
| Input Voltage | 100 to 240 VAC, 100 to 240 VDC |
| Certifications | IEC 61850-3 |
Features and Benefits
- 10/100BaseT(X) auto-negotiation and auto-MDI/MDI-X
- Link Fault Pass-Through (LFP)
- Power failure alarm by relay output (LV model only)
- -40 to 85°C operating temperature range
- Redundant dual DC power inputs (LV model only)
- Integrated high-reliability power supply eliminates the need for external power transformer
- Compliant with EN 50121-4
- Complies with all EN 50155 mandatory test items*
- *This product is suitable for rolling stock railway applications, as defined by the EN 50155 standard. For a more detailed statement, click here: www.moxa.com/doc/specs/EN_50155_Compliance.pdf
